Testo 512 Manometer, 0-2000 hPa

Model: 512 | Order No: 0560 5129 | UPC: 4029547004315

Downloads: datasheet manual

Testo 512 Manometer, 0-2000 hPa

Model: 512 | Order No: 0560 5129

Displays pressure in an easy-to-read, large, backlit display. Measurement data is printed on site with date and time as well as minimum and maximum values.

Discontinued!

This product has been discontinued and is no longer available.

There is no direct replacement, however we recommend the:

Testo 512-1 Digital Differential Pressure Gauge, 0 to 80 inH₂O

Model: 512-1 | Order No: 0563 1512

Fast, easy, and precise, this pressure gauge provides reliable and accurate differential pressure measurements of 0 to 80 inH₂O to check filters and Pitot tube measurements in ventilation ducts. In addition, the Smart App allows fast in-app (duct) configuration, graph history, second screen, and stores measurement data.

Learn More

Testo 512-2 Digital Differential Pressure Gauge, 0 to 800 inH₂O

Model: 512-2 | Order No: 0563 2512

Fast, easy, and precise, this pressure gauge provides reliable and accurate differential pressure measurements of 0 to 800 inH₂O to check filters and Pitot tube measurements in ventilation ducts. In addition, the Smart App allows fast in-app (duct) configuration, graph history, second screen, and stores measurement data.

Learn More

Not what you're looking for? Let’s do a search and help you find what you need.

Recommended Accessories

Testo 0516 1201 Hard Carrying Case

0516 1201

Testo 0516 0221 TopSafe Protective Cover

0516 0221

Testo 0554 0549 Universal Infrared Printer

0554 0549

Testo 0554 0568 Thermal Printer Paper, 6 Rolls

0554 0568

Testo 0635 2045 Stainless Steel Pitot Tube, 19.5" Long

0635 2045

Testo 512 Offers

Pressure and flow velocity measuring instrument 0 to 800 hPa

Testo 512 Features

8 switchable units of pressure: kPa, hPa, Pa, mm H₂O, mmHg, psi, inch H₂O, inch Hg
Integrated density compensation

Testo 512 Technical Data

Pressure sensor integrated
Storage temperature	+14 to +158 °F
Operating temperature	+32 to +140 °F
Battery type	9V battery
Battery life	120 hr
Dimensions	7.95 x 2.24 x 1.65 in
Housing material	ABS
Measuring range	0 to +800 inH2O
Accuracy	0.5% of f.v.
Resolution	1 inH2O

Click here for complete specifications on the Testo 512

What's Included with the Testo 512

Testo 512
Calibration Certificate
Batteries

datasheet for the Testo 512 Manometer, 0-2000 hPa manual for the Testo 512 Manometer, 0-2000 hPa

Click on a category to view a selection of compatible accessories with the Testo 512 Manometer, 0-2000 hPa.

Carrying Cases

Testo 0516 1201 Hard Carrying Case 0516 1201

Fitted foam padded interior, centered handle, and 2 closing latches. Measures 70 x 85 x 405mm.

Testo 0516 0221 TopSafe Protective Cover 0516 0221

The TopSafe protection case is waterproof, dishwasher-safe, and indestructable. For use with the 110, 416, 417, 425, 512, 625, 720, and 925.

Communications

Testo 0554 0549 Universal Infrared Printer 0554 0549

Includes a Wireless Infrared Interface, 1 Roll of Thermal Paper and 4xAA Batteries.

Testo 0554 0568 Thermal Printer Paper, 6 Rolls 0554 0568

For use with the 575 Printer. Measurement data documentation legible for up to 10 years. Package of 6 rolls.

Pitot Tubes

Testo 0635 2045 Stainless Steel Pitot Tube, 19.5" Long 0635 2045

500 mm long, for measuring flow velocity.

Ask a question about Testo 512 Manometer, 0-2000 hPa

Customer Reviews for the Testo 512

Description ➕➖

Testo 512 Offers

Pressure and flow velocity measuring instrument 0 to 800 hPa

Testo 512 Features

8 switchable units of pressure: kPa, hPa, Pa, mm H₂O, mmHg, psi, inch H₂O, inch Hg
Integrated density compensation

Specifications ➕➖

Testo 512 Technical Data

Pressure sensor integrated
Storage temperature	+14 to +158 °F
Operating temperature	+32 to +140 °F
Battery type	9V battery
Battery life	120 hr
Dimensions	7.95 x 2.24 x 1.65 in
Housing material	ABS
Measuring range	0 to +800 inH2O
Accuracy	0.5% of f.v.
Resolution	1 inH2O
